In the process of air, gas and steam treatment, 99% of liquid and solid impurities larger than 10 μ M can be removed automatically by using the type TS gas / liquid separator. There are no moving parts inside the separator, so there is no need for maintenance. Product characteristics The wet gas enters the separator from the inlet and begins to centrifugal downward due to the swirling flow. Solid and liquid impurities are separated due to a decrease in speed. The separated liquid and solid impurities fall into the liquid storage cavity with unique VCP baffle design, so that the impurities will not form secondary pollution. The clean, dry air flow will then be directed directly to the outlet by the VCP. In this way, expensive and fragile ordinary separator baffles are omitted. ★ designed to meet the application of high liquid load ★ achieve efficient separation in a wide range of flow without maintenance ★ remove 99% solid and liquid impurities larger than 10 microns application area The model TS gas / liquid separator is used in the application of heavy liquid load, which is easy to cause "water hammer" problem. They are widely used in refineries and chemical plants. In many cases, when it is necessary to use instruments to control the liquid level in the liquid storage cavity, the liquid holding capacity will be required. In some common applications, the separator can be used in the upstream of the gas turbine, absorption tower, gas scrubber and steam generator outlet. Custom structure TS type separators can be socket welded, threaded and 150 -, 300 -, or 600 pound flanged, and manufactured from custom-made carbon steel, stainless steel, or other alloys. According to the size of separator, the liquid holding capacity can be changed from 5.38l to 924.26l, and larger liquid holding capacity can also be adopted according to the application needs. Separators can be manufactured according to ASME steel seal standard or integrated feet can be selected as required.
