The ultra fast opening multi bag filter is specially designed for the users who pay attention to efficiency, safety and durability. It is mainly used in the occasions where there are many impurities, the filter elements need to be replaced frequently or the filter needs to be switched quickly in continuous production. The filter is a sharp tool to greatly improve the production efficiency. The replacement of filter elements is fast and reliable, which effectively reduces the impact of production interruption caused by the replacement of elements It improves the efficiency of production and greatly reduces the labor intensity of workers.

Operation process: The bag filter is easy to operate. Only install the filter bag with required fineness grade in the filter cartridge, check whether the O-ring is intact, and then screw the ring bolt of the filter cartridge cover to put it into operation. After the pump is started, the pressure gauge on the filter rises slightly, with the initial pressure of about 0.05Mpa. With the extension of the use time, the filter slag in the cylinder increases gradually. When the pressure reaches 0.4MPa, stop the machine and open the cylinder cover, check the residual slag in the filter bag, and replace the filter bag to continue to use (the filter bag can be reused generally through cleaning). The filter pressure is generally adjusted at 0.1-0.3mpa, which can be adjusted through the return line or the return valve on the pump. If the filter pressure is too high, it will damage the filter bag and the protection net, so special attention should be paid.

Product material: Sealing gasket: silica gel, NBR, Teflon rubber. Filter bag material: polyester, polypropylene, nylon, polytetrafluoroethylene, glass fiber Shell material: stainless steel SS304 (06cr19ni10), SS316L (022cr17ni12mo2), carbon steel (16MnR), Hastelloy (C276), carbon steel lining. Product features: 1. The quick switch mechanism is a relatively simple, easy-to-use and safe operating system with short downtime, high production efficiency and low operating cost. 2. It only takes more than ten seconds for the filter to open and close, and the instantaneous pressure of the cover opening is released automatically, so the operation is safe and without danger. 3. The unique three-point pressure ring ensures a good seal between the filter and the filter bag, and the side in and bottom out design ensures that the liquid can be completely discharged. 4. The spring assisted weight balancing mechanism makes the top cover as light as nothing. You only need to push or pull the top cover gently by hand to open or lower it. 5. The parts in contact with the liquid are all made of high-quality stainless steel, which has anti-corrosion effect on a variety of liquids. Another simple design can be applied to various processes and applications. 6. The design and volume of the filter are compact, reducing the loss of liquid to a minimum. The number of applicable filter bags is 4-12 bags (01 × 104m3 and 02 × 104m3). Change the filter bag: Product advantages: ◆ open and close the filter within 15 seconds at most, and replace the filter elements quickly. ◆ open and close the filter at a fixed position without fastening the nuts around the filter; ◆ with safety interlock design, the filter can be opened only after the exhaust pressure is relieved; ◆ gravity balance auxiliary cover opening mechanism, which can push the upper cover to any open angle with one finger; ◆ copper nut design, the thread is no longer combined with wire, and the rotation is more time-saving and labor-saving. ◆ the liquid connection part is made of pure stainless steel, with excellent corrosion resistance and durability; ◆ minimize downtime, promote productivity and reduce operation cost. ◆ select high-quality O-type elastomer seal ring, excellent sealing performance and sealing life; ◆ open the upper cover vertically, multiple sets can be connected in compact parallel, saving installation space and piping cost. ◆ special tool for fastening the pressure ring of special filter bag is attached, easy to operate and labor-saving; ◆ 8 models, three bags, four bags, five bags, six bags, eight bags, twelve bags, seventeen bags and twenty-three bags respectively; ◆ three kinds of import and export orientation layout are optional, convenient for design and installation
